| Categories | Hydraulic Borewell Machine |
|---|---|
| Brand Name: | ShiTan |
| Model Number: | GK-200 |
| Certification: | ISO9001 |
| Place of Origin: | China |
| MOQ: | 1 set |
| Price: | USD4500-5800/SET |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 20000 sets per year |
| Delivery Time: | Within 7-12 days |
| Packaging Details: | wooden box |
| Name: | Small Hydraulic Type GK 200 Meters Borehole Drilling Machine |
| Power Type: | diesel or motor |
| Voltage: | 220v |
| Dimension(L*W*H): | 1730*860*1360 |
| Application: | water well,railways, core |
| Type: | Small core drill rig |
| Max Drilling Depth: | 200 meter |
| Drilling diameter: | 260mm |
| Condition: | New |
| Color: | Customized |
| Company Info. |
| Jinzhou City Shitan Machinery Equipment CO. LTD. |
| Verified Supplier |
| View Contact Details |
| Product List |
Mobile Crawler Water Well Drilling Rigs Hydraulic Borewell Drilling Equipment
It is an efficient and multi-functional device of deep water well drill rig, which is mainly applied to industrial and civil drilling and geotemperature drilling. It has the advantages of large diameter of drilling hole, deep drilling, fast footage, and so on. It has reliable quality and long service life. And it is easy to operate and maintain.
GK 200 Meters Borehole Drilling Machine Tech Data
| GK 200 Borehole Drilling Rig | |
| Drilling diameter(mm) | 75,91,110,130,150,300 |
| Drilling depth (m) | 200,150,100,70,50,30 |
| Drill pipe diameter (mm) | 42,50 |
| Drilling angle(°) | 90~75 |
| Equipment size(L * B * H) | 1730 * 860 * 1360 (mm) |
| Rig weight (except engine) | 700 |
| Mobile device | |
| Moving length | 350mm |
| Leave distance | 300mm |
| Gyrator | |
| Spindle speed (four gear) (r/min) | 115,230,505,1010 |
| Spindle travel(mm) | 450 |
| Spindle no-load lifting maximum moving speed(m/s) | 0.05 |
| Spindle no load drop maximum movement speed(m/s) | 0.067 |
| Spindle maximum feed pressure(KN) | 15 |
| Spindle maximum lifting force(KN) | 25 |
| Spindle maximum output torque(KN• m) | 1.5 |
| Winch assembly | |
| Winch maximum lifting force (single rope) | 20 |
| Reel speed (r/min) | 20,39,85,170 |
| Reel circumferential speed(m/s) | 0.172,0.345,0.738,1.476 |
| Reel diameter(mm) | 140 |
| Wire rope diameter(mm) | 9.3 |
| Wire rope density (m) | 40 |
| Brake diameter(mm) | 278 |
| Brake band width (mm) | 50 |
| Oil pump | |
| Oil pump type | YBC -20/125 |
| Nominal pressure (Mpa) | 12.5 |
| Rated flow(ml/r) | 20 |
| Rated speed(r/min) | 800-2500 |
| Diesel engine or motor | |
| Diesel engine | 1115 |
| Rated power (KW) | 16.2 |
| Rated speed (r/min) | 2200 |
| Rated pressure(Mpa) | 12.5 |
| Motor type | Y160M - 4 |
| Rated power (KW) | 11 |
| Rated speed (r/min) | 1460 |
GK 200 Meters Borehole Drilling Rig Machine Drill Purpose
The Characteristics Of Small Hydraulic Type GK 200 Meters Borehole Drilling Machine
1. Adopt Low speed high torque hydraulic motor drive rotary device
output torque
2. The advantage of cylinder is promoting more stable, less failure
significantly than the motor propulsion.
3. Equip two filter effectively to ensure the safety of diesel
engine intake and prolong engine life.
4. It can readily monitor rig hydraulic system pressure and boost
pressure to ensure the rig stable and efficient operation.
5.Using well-known brands of multi-way control valve, superior
performance, handle centralized, easy to operate.
Jinzhou Shitan Machinery Equipment Co., Ltd. Main Products：
Pneumatic Drilling Rig / Air Drilling Rig（ST-180, ST-200, ST-260, ST-300, ST-350, ST-400, ST450, ST-450, ST-500, ST-600, ST-800 and other Pneumatic water well drilling Rigs.）, Crawler Water Well Drilling Rig / Trailer Mounted Drilling Rig / Water Well Drilling Rig / Hydraulic Borewell Machine / Hard Rock Drilling Equipment / Diamond Core Drill Rig / Geological Drilling Rig / Soil Testing Drilling Rig / Portable Water Well Drilling Rig（ST-30，ST-50，XY-1A, XY-1B, XY-2, XY-2B, GK180, GK200, GY150, GY200 and 30 impact drill rig, ZLJ series tunnel drilling rig and other geological drilling machines）Crawler Track Undercarriage, Drilling Mud Pump（BW150,BW160,BW200,BW250,BW850 series Drilling mud pumps）, Drilling Air Compressor, Water Well Drill Bits（PDC Drill Bit， Tricone Bit， DTH Button Bit）, Water Well Drill Pipe, Drilling Rig Spare Parts( drilling rods , drilling rods joint , casing pipe, casing coupling, core tube, core tube coupling, lifters, automatic drop hammer, sampler, SPT tool, wrench fork, pad fork, lock joint), Track Transporter
OEM / ODM can accept. Good quality, professional after-sales service, welcome to order
|
