| Categories | Polypropylene Film Capacitor |
|---|---|
| Brand Name: | ETOPMAY |
| Model Number: | TMCF15 |
| Certification: | SGS( RoHS), UL |
| Place of Origin: | China |
| MOQ: | 5000pcs |
| Price: | Negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 1000000pcs per month |
| Delivery Time: | 15~20 working days |
| Packaging Details: | Bulk, Tape |
| Capacitance: | 680nF |
| Voltage: | 250VDC |
| Pitch: | 15mm |
| Material: | Polypropylene |
| Tolerance: | +/-10% |
| Operating Temperature: | -40~+85C |
CBB21 Metallized Polypropylene Film Capacitor MKP 684K250V For Filtering Circuits
Cbb21/22 (MPP) Metallized polypropylene film capacitor belongs to the largest category of film capacitors. It is wound with metallized polypropylene film, sealed externally with epoxy resin, non-inductive structure, with less loss, small internal temperature rise, can withstand high pulse, large current, high frequency resistance, less capacity change, negative temperature coefficient and other advantages.
CBB21 capacitors are widely used in high frequency, DC, AC and pulse circuits and are widely used in high current applications.
Features
Metallized polypropylene film, epoxy resin coating
Low dissipation factor with high frequency
Small inherent temperature rise
High insulation resistance, good self-healing property
Suitable for DC, pulse, high frequency and high current circuits
S-shaping correction of color TV sets
Outline Drawing
Non-inductive, wound with metallized polypropylene film as the
dielectric and
welectrode ,with copper-clad steel leads and epoxy resin coating.
Specifications
| Reference Standard | GB100190-88(IEC 60384-16) |
|
| Climatic Category | 40/85/21 | |
| Rated Voltage | 250VAC | |
| Capacitance Range | 0.68uF | |
| Capacitance Tolerance | 10%(K) | |
| Voltage Proof | 1.6UR(5s) | |
| Dissipation Factor | ≤0.1%(20°C, 1KHz) | |
Insulation Resistance (20℃ ,1min) | ≥25000MΩ (CR≤ 0.33 uF) |
| W(mm)±1.0 | T(mm)±1.0 | H(mm) | P(mm) | ||||
| 17 | 6.2 | 11 | 15 |
Our series of strong products of capacitors can be divided into below types:
★ Ceramic Disc Capacitor( low and high voltage, Y1/Y2 safety )
★ Multilayer Ceramic Capacitor( radial, axial and SMD )
★ Film Capacitor( Mylar, MKT, MKP, X2, CBB60, CBB61, CBB65, CL21-Box, CBB-BOX, CL20, CBB20, CBB81, etc. )
★ Aluminum Electrolytic Capacitor(SMD, Radial , Axial, Snap-in , Screw Terminal, etc. )
★ Tantalum Capacitor(SMD, Radial , Axial )
★ Super Capacitor( Coin Type, Cylindrical Type, Module Type)
★ Mica Capacitor
★ Trimmer Capacitor
And series of resistors which we develop new production lines are as below:
★ SMD Resistors
★DIP TYPE Resistors( KNP, CF, MF, MOF, ect,)
★ Cement Resistors
★ Leadless Resistors( MLEF)
★Power Resistor
More details, Kindly contact us freely!
|
