Dehydrated Vegetables Optical Color Sorter AI Optical Sorting Equipment

Categories Fruit Sorter Machine
Brand Name: PHOENIX
Model Number: HD AI Optical Sorter
Place of Origin: Hefei
MOQ: 1
Price: Price Negotiable
Payment Terms: L/C,D/A,D/P,T/T,,
Delivery Time: 5-8 work days
Model: HD2
Belt Width (mm): 600
Air Nozzle: 256
Air Pressure (MPa): 0.6~0.8
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Dehydrated Vegetables Optical Color Sorter AI Optical Sorting Equipment

HD AI Optical Sorter

An AI-driven high-precision defect sorting and quality grading equipment for dehydrated vegetables, delivering industry-leading accuracy in sorting.

Technical Features
  • High-end sorting solution specifically designed for dehydrated vegetables
  • Compact dual-belt sorting system: Supports quick installation and features simultaneous re-screening
    • Primary sorting: Conducted on the upper belt to efficiently remove all potential defects (including a minimal amount of good product)
    • Secondary sorting: Re-inspects and recovers good product from the primary rejects on the lower belt, improving yield
  • Innovative high-capacity dual-layer vibrating feeder: Spreads material evenly into a single layer, significantly reducing overlap
  • Full food-grade stainless steel construction: Complies with global food safety and hygiene standards
  • Sealed dust-proof control cabinet: Provides high-level protection for the equipment
  • Field-proven dust removal system: Ensures long-term stable operation, maintains consistent performance, and significantly reduces downtime
  • Quick belt replacement design: Facilitates daily maintenance and cleaning, meeting higher hygiene requirements
  • Modular belt width (600/800/1000/1200 mm): Offers flexible configuration options for processors
AI-Driven Quad-Spectrum Detection System
  • Proprietary AI deep learning algorithm: Continuously optimizes defect recognition models based on new samples
  • High-resolution RGB camera system
  • High-brightness LED lighting system
  • Optional InGaAs-SWIR camera system
  • Optional UV fluorescence camera system
  • Industry-leading detection accuracy: Identifies various defects based on color, size, shape, texture, and other features, including:
    • Color defects: Browning, discoloration, scorch marks, mildew spots, peel residues
    • Shape defects: Broken pieces, fragments, clumps, deformation, substandard products, incorrect sizing
    • Drying defects: Uneven dehydration, sugar crystallization, rehydration stains
    • Foreign material contamination: Plastic/rubber fragments
    • Biological contamination: Microbial colonies
High-Performance Ejection System
  • Reinforced durable design with optimized operating speed and air consumption
  • Ensures precise ejection and stable operation in high-capacity sorting scenarios
  • Significantly reduces false rejection rates and effectively controls the total cost of ownership over the equipment’s lifecycle
Specifications
ModelBelt Width (mm)Air NozzleAir Pressure (MPa)Air Consumption (m³/min)VoltagePower (kW)Dimension (mm)Unpacked Weight (kg)
HD26002560.6~0.8<2.0220V~50/60Hz6.43641×1540×28041376
HD412005120.6~0.8<4.1220V~50/60Hz7.93641×2140×28041917
