| Categories | Furniture Testing Equipment Series |
|---|---|
| Brand Name: | Haida |
| Place of Origin: | Guangdong, China |
| Model Number: | HD-F754 |
| MOQ: | 1 |
| Price: | $1,800-2,100 |
| Ball diameter: | 16 ± 0.05 mm |
| Ball mass: | 16.8g ± 1.5 g |
| Drop height: | 500±0.5%mm |
| Rebound rate accuracy: | <0.5% |
| Sample size: | 100 mm × 100 mm × 50 mm |
| Machine dimensions: | 575 × 305 × 630 mm |
| Power consumption: | 0.1 KW |
| Display type: | LCD Touch Screen |
| Sensor type: | Optical fiber sensor |
| Test results: | Rebound height, rebound rate, average rebound rate |
| Test standard: | ASTM D3574, ISO 8307 |
| Ball drop distance: | 460 ± 0.5%mm (GB), 500 ± 0.5%mm (American Standard) |
| Output method: | Built-in printer |
| Control type: | Microprocessor |
| Measurement accuracy: | <1.5% |
| Company Info. |
| Haida Equipment Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
| Parameter | Specification |
|---|---|
| Drop Height | 500±0.5% mm |
| Drop Ball | Diameter: ￠16±0.05 mm, Mass: 16.8g ± 1.5 g |
| Accuracy | <1.5% |
| Display | LCD Touch Screen Interface |
| Sensor | Optical Fiber Sensor |
| Test Results | Rebound height, rebound rate, and average rebound rate after 5 test cycles |
| Sample Size (L×W×H) | 100 mm × 100 mm × 50 mm |
| Machine Dimensions (L×W×H) | 575 × 305 × 630 mm |
| Test Results Output | Built-in Printer |
| Power Consumption | 0.1 KW |
| Items | Details |
|---|---|
| Documents | Operation Manual ×1 piece Factory Inspection Report ×1 piece Operation Video in USB flash disk with machine ×1 piece |
| Power Line | 1 piece |
| Plug | 1 piece (Per your local plug standard) |
| Optical Fiber Ranging Sensor | 1 Set |
| Micro-Printer | 1 Set |
| Touch Screen | 1 piece |
| PLC | 1 piece |
| Electrical Accessories | 1 Set |
| Specimen Holder | 1 Set |
| Packing Box | 1 Set (Includes two steel balls and one sampling rod) |
|
