S30403 1.4307 Seamless Stainless Steel Tubing
ASTM Cold Drawn Stainless Steel Tube - Professional manufacturing
of high-quality stainless steel tubing for industrial applications.
Product Specifications
| Product Name | 304 Stainless Steel Pipe |
|---|
| Type | Seamless Pipe / Welded Pipe |
|---|
| Shape | Round |
|---|
| Diameter | OD6 - 630mm |
|---|
| Wall Thickness | SCH5 SCH10 SCH40 SCH80 SCH160 or custom as requested |
|---|
| Length | 6m/pc or custom cutting as requested |
|---|
| Standard | ASTM DIN EN GB |
|---|
| Main Grades | 304 304L 309S 310S 316L 316Ti 316LN 317L 321 329 347 410 2205 2507
904L C276 etc. |
|---|
| Company Type | Storage and Factory |
|---|
| Service | Cutting Polishing |
|---|
Material Description
About 304/304L Stainless Steel
AISI 304 stainless steel (UNS S30400) is the most widely used
stainless steel, containing 18-20% Cr and 8-10.5% Ni, also known as
18-8 stainless steel. SS 304 is non-magnetic under annealing
conditions but may become weakly magnetic after cold working
processes. Type 304 offers excellent resistance to atmospheric
corrosion and oxidation, with high nickel-chromium alloy content
providing superior corrosion resistance, making it the standard
food grade stainless steel in the food industry.
Chemical Composition of 304 Stainless Steel
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
|---|
| 304 | 0.08 max | 2.0 max | 0.75 max | 0.045 max | 0.030 max | 18.0-20.0 | - | 8.0-10.5 | 0.10 max |
| 304L | 0.030 max | 2.0 max | 0.75 max | 0.045 max | 0.030 max | 18.0-20.0 | - | 8.0-12.0 | 0.10 max |
| 304H | 0.04-0.10 | 2.0 max | 0.75 max | 0.045 max | 0.030 max | 18.0-20.0 | - | 8.0-10.5 | 0.10 max |
Mechanical Properties of 304 Stainless Steel
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50 mm) min | Rockwell B (HR B) max | Brinell (HB) max |
|---|
| 304 | 515 | 205 | 40 | 92 | 201 |
| 304L | 485 | 170 | 40 | 92 | 201 |
| 304H | 515 | 205 | 40 | 92 | 201 |
Product Gallery
Company Information

Our company is a professional stainless steel seamless tube
manufacturing enterprise located in Wuxi city, China's stainless
steel material distribution center. Situated 100 kilometers from
Shanghai port, we benefit from convenient transportation access.
We specialize in sales and production of high-temperature (nickel
base) alloy, austenite, duplex steel, urea grade stainless steel,
super stainless steel and other series of steel tubes, coils, pipe
fittings, flanges and related products.
Our production capabilities include:
- Annual output of 25,000 tons of stainless steel seamless pipe
production line
- 20,000 tons of welded pipe production line
- 5,000 tons of pipe fittings production line
We produce according to GB, ASTM, JIS, DIN and other standards,
manufacturing:
- Stainless steel seamless pipe: φ6 ~ φ762×0.5 ~ 70mm
- Stainless steel welded pipe: φ15 ~ φ2200×0.5 ~ 80mm
- Pipe fittings and related products
Main grades include TP321, TP316Ti, S32205, TP347H, TP316L, TP310S,
TP304, TP304L, 321, S32750, 904L, C276, 254SMO and more.
With modern technology and equipment, advanced foreign technology
integration, and continuous improvement initiatives, our product
quality consistently rises, making us one of the most competitive
enterprises in the industry.
