65Mn Spring Steel Overview
We are GB 65Mn steel stockholders and China suppliers. Mittel Steel
supplies GB 65Mn Spring Steel in round bar, flat bar, rod bar,
wire, and plate formats. GB 65Mn Steel is a high-quality alloy
spring steel belonging to the high-quality high carbon alloy spring
steel category. Its quenched & tempered hardness is 28-34 HRC, and
under annealing delivery, hardness is less than 250HB.
Related Specifications
ASTM A29/A29M, DIN EN 17221, JIS G4801, GB/T 1222 GB 65MN Spring
Steel
Form of Supply
GB 65Mn Spring Steel China Supplier and Stockist. Otai Special
Steel can supply round bar, steel flat bar, plate, hexagonal steel
bar, and steel square block. AISI 65Mn steel round bar can be
saw-cut to your required lengths as one-offs or multiple cut
pieces. 65Mn steel rectangular pieces can be saw-cut from flat bar
or plate to your specific sizes. Ground spring steel bar can be
supplied, providing quality precision finished bar to tight
tolerances.
Chemical Composition
| Element | Content (%) | Element | Content (%) |
|---|
| C | 0.62-0.70 | Si | 0.17-0.37 |
| Mn | 0.90-1.20 | P | ≤0.035 |
| S | ≤0.035 | Cr | 0.25max |
| Ni | 0.25max | | |
Equivalent of 65Mn Alloy Spring Steel
| USA | Germany | China | Japan | France | England | Italy | Poland | ISO | Austria | Sweden | Spain |
|---|
| AISI/SAE/ASTM/UNS 1066 | | 65Mn | | | 080A67 | | | | | | |
Heat Treatment
- Annealing of 65Mn Spring Steel: Slowly heated to 730°C and allowed sufficient time for thorough
heating, then cooled slowly in the furnace. Resulting hardness: MAX
250 HB.
- Hardening of 65Mn Spring Steel: Heated uniformly to 830-860°C (1526-1580°F) until completely
heated through. Provide about 30 min per 25 mm of ruling section,
then immediately quench in oil.
- Tempering of 65Mn Spring Steel: Performed at 540°C. Soak well at selected temperature for at least
one hour per 25mm of total thickness.
Mechanical Properties
| Tensile Strength | Yield Strength | Elongation | Reduction of Area | Hardness (Hot Rolled) | Hardness (Cold Drawn) |
|---|
| σb (MPa): ≥980 | σ0.2 (MPa): ≥785 | δ 5 (%): ≥8 | ψ (%): ≥30 | ≤302HB | |
Applications
65Mn steel, after heat treatment and cold drawing hardening,
exhibits high strength with certain toughness and plasticity. In
surface hardening cases, it achieves complete fatigue limits
comparable to alloy spring steel. However, hardenability is poor,
making it mainly suitable for smaller size springs such as
regulating speed springs, load springs, round and square spiral
springs in general machinery, or pull wire for small mechanical
springs.
Regular Size and Tolerance
Steel round bar: Diameter Ø 2mm - 3000mm
Steel plate: Thickness 2mm - 3000mm x Width 100mm - 3500mm
Steel Hexagonal bar: Hex 5mm - 105mm
Other 65Mn sizes not specified - please contact our experienced
sales team.
Processing
GB 65Mn Spring Steel round bar and flat sections can be cut to your
required sizes. 65Mn Spring Steel ground bar can also be supplied,
providing high-quality spring steel precision ground bar to your
required tolerances. GB 65Mn steel is also available as Ground Flat
Stock / Gauge Plate in standard and non-standard sizes.
Contact our experienced sales team to help with your 65Mn Spring
Steel questions and inquiries by Email or Telephone. All questions
will be replied to within 24 hours.
