| Categories | ZHAGA Controller |
|---|---|
| Brand Name: | LongJoin |
| Model Number: | JL-772B2 |
| Place of Origin: | China |
| Price: | negotiable |
| Packaging Details: | Different packaging methods are adopted according to different modes of transport. |
| Payment Terms: | Western Union,MoneyGram,T/T |
| Power Supply: | Rated voltage：12~24VDC Rated current：40mA |
| Power Consumption: | ＜0.6W |
| Sensor Type: | Light-sensitive + Microwave |
| Dimming interface: | Type：0~10V Accuracy：±2% |
| Certifications: | RoHS,CE |
| Real-world Scenarios: | Tunnel & Underpass Lighting |
| Company Info. |
| Shanghai Long-Join Intelligent Technology Inc |
| Verified Supplier |
| View Contact Details |
| Product List |
JL-772B2 is an intelligent interlocking controller developed based on standards similar to Z10 interface, using light sensing + microwave mobile combination sensor. It outputs 0~10V dimming signal and is equipped with Bluetooth mesh communication network for control and configuration via APP. Suitable for roads, lawns, courtyards, parks, parking lots, industrial mines and other lighting scenes. Specifically designed for UFO lamps with Z10 socket.
| Model | JL-772B2 |
| Power Supply | Rated voltage: 12~24VDC, Rated current: 40mA |
| Power Consumption | <0.6W |
| Sensor Type | Light-sensitive + Microwave |
| Spectral Acquisition Range | 860~1100nm, Peak wavelength 960nm |
| Maximum Hanging Height | 15M |
| Sensing Radius | >10m (at 15m hanging height) |
| Anti-jump Delay | 3S (minimum interval time for turning on after light is off) |
| Hold Time | Default 30S, APP adjustable |
| Stand-By Brightness | Default 0%, APP adjustable |
| Stand-By Time | Default 5S, APP adjustable |
| Dimming Interface | Type: 0~10V, Accuracy: ±2% |
| Turn On Illuminance | APP adjustable, 5 levels: Daytime, Dusk, Evening, Night, Late night |
| Energy Saving Strategy | Customizable |
| Mechanical Vibration | IEC60068-2-6 |
| Flammability Level | UL94-V0 |
| Operating Temperature | -40℃~70℃ |
| Storage Temperature | -40℃~85℃ |
| Operating Humidity | 5%RH~99%RH |
| IP Level | IP66 |
| Certifications |  |
A: It is an intelligent motion sensor controller equipped with both light sensing and microwave detection, adopting the standard American Z10 interface, used for automatic motion-activated lighting control.
A: The Z10 interface follows the North American standard for outdoor lighting, featuring high compatibility, plug-and-play installation, waterproof structure, and easy replacement on street lights and fixtures.
A: Light sensing ensures the controller only works at night or in low light, while microwave detects moving people or vehicles to trigger lighting automatically, achieving high energy efficiency.
A: Microwave radar can sensitively detect moving objects, automatically turn on the light when someone passes by, and delay turning off after people leave, realizing intelligent motion control.
A: It is widely used in roads, lawns, courtyards, parking lots, residential areas and other outdoor lighting places requiring automatic motion control.
|
