| Categories | Tripod Turnstile |
|---|---|
| Supply Ability: | 1000sets/month |
| Size: | 1200×280×980mm |
| MOQ: | 1 SET |
| Certification: | ISO9001 |
| Working Voltage: | DC24V / DC12V |
| Packaging Details: | Export-standard wooden box |
| Brand Name: | Shenzhen Jieshida Technology Co., Ltd |
| Price: | USD 300-1,500 |
| Delivery Time: | 5-8 working days |
| Payment Terms: | T/T |
| Material: | 304 Stainless Steel |
| Power Supply: | AC220V±10%, 50Hz±4% |
| Place of Origin: | China |
| Passage Width: | 550mm |
| Opening Time: | 0.5S |
| Model Number: | JSD-Z01 |
| Company Info. |
| Shenzhen Jieshida Technology Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
The Anti-reverse Tripod Turnstile Gate is a reliable access control solution for secure pedestrian entry management. Built with 304 stainless steel, it offers strong durability, anti-corrosion performance, and stable operation for long-term use. The gate supports remote control and RFID access, helping manage one-way or bi-directional passage efficiently. With anti-reverse protection, smooth rotation, and easy integration with modern access systems, it is ideal for offices, factories, schools, stations, and other secure entry points.
Office Building
Tripod turnstile gates help control employee access, prevent
unauthorized entry, and improve daily attendance management in
office environments with stable pedestrian flow.
Factory
In factories, tripod turnstiles provide reliable worker access
control, reduce unauthorized entry into production areas, and
support shift attendance tracking for better workforce management.
School
Tripod turnstile gates enhance campus security by managing student
and visitor access while preventing unauthorized individuals from
entering school facilities.
Residential Community
For residential communities, tripod turnstiles improve pedestrian
entrance management and strengthen community security through RFID
card or QR code verification.
Subway Station
At subway stations, tripod turnstiles efficiently manage high
passenger traffic, reduce fare evasion, and maintain orderly entry
and exit during peak commuting hours.
Government Building
Tripod turnstiles help government buildings strengthen security
control by limiting access to authorized personnel and improving
entrance management efficiency.
Commercial Center
In commercial centers, tripod turnstiles help organize visitor
flow, improve security management, and support controlled access in
busy public areas.
Exhibition Hall
For exhibition halls, tripod turnstiles support ticket
verification, improve crowd management efficiency, and help
maintain organized visitor entry during large events.
| Parameters | Value |
|---|---|
| Drive Mode | Motor / Solenoid Valve |
| Passage Direction | One-way / Two-way |
| Opening Time | 0.5S |
| Anti-reverse Function | Support |
| Power Supply | AC220V±10%, 50Hz±4% |
| Working Voltage | DC24V / DC12V |
| Traffic Speed | ＞30 Persons/Minute |
| Operating Noise | ＜50DB |
| Communication Interface | RS485 (≤1200m), TCP/IP Optional |
| Input Signal | Dry Contact / 12V Pulse Signal |
| Working Environment | Indoor / Outdoor (Awning Recommended) |
| Working Temperature | -10℃ ~ 60℃ |
| Relative Humidity | 5% ~ 95%, No Condensation |
| Passage Width | 500-550mm |
| Arm Length | 510mm |
| Net Weight | 45KG |
| Cabinet Material | 304 Brushed Stainless Steel |
| Cover Thickness | 1.2mm |
| Cabinet Thickness | 1.0mm |
| Dimension | 1200*280*980mm |
|
