HX36B Automatic Notebook Elastic Band Fixing Machine Applies And Fixes Elastic Bands On The Notebook

Categories Notebook and Exercise Book Making Machine
Model Number: HX36B
Packaging Details: Stretch Film with Wooden Case
Distance from Hole to Cover Edge Side: 0-40mm
Working Speed: 2000pcs/h
Cover Thickness: 0.7-7mm
Dimensions: 1600×930×1385(L×W×H)
Power: 8KW
Elastic Band Length: 0-160mm
Width of Elastic Band: 6-10mm
MOQ: 1 set
Voltage: 220V
Brand Name: HXCP
Distance between 2 Holes: 40-271mm
Weight: 310KG
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 10 sets/month
Delivery Time: 30 work days
Min Cover Size: 70×100mm(W×L)
Place of Origin: China
Max Cover Size: 300×420mm(W×L)
Distance from Hole to Upper and Bottom Side: 9-100mm
Certification: CE
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

HX36B Automatic Notebook Elastic Band Fixing Machine Applies And Fixes Elastic Bands On The Notebook

HX36B Automatic Notebook Elastic Band Fixing Machine


Description



HX36B Automatic Notebook Elastic Band Fixing Machine applies and fixes elastic bands on the notebook cover fully automatically. It handles feeding, punching, threading, cutting, gluing, fixing, and stacking – all within a compact footprint. Powered by servo motors, this highly automated machine ensures efficient, stable operation with minimal downtime, achieving over 10 times the output of manual production. Operators can store and recall 10 job settings for rapid setup changes between runs. Works on hardcovers, softcovers, and pre-cased notebooks. Easily switches to semi-auto mode for manual feeding when for smaller batches or testing.


Parameters


Model
HX36B
Min Cover Size
70×100mm(W×L)
Max Cover Size
300×420mm(W×L)
Working Speed
2000pcs/h
Distance between 2 Holes
40-271mm
Distance from Hole to Upper and Bottom Side
9-100mm
Distance from Hole to Cover Edge Side
0-40mm
Elastic Band Length
0-160mm
Cover Thickness
0.7-7mm
Width of Elastic Band
6-10mm
Dimensions
1600×930×1385(L×W×H)
Power
8KW
Voltage
220V
Weight
310KG



Products Show






Details


FAQ:

Q: What is the brand name of this product?
A: The brand name of this product is HXCP.
Q: Does this product come with any certification?
A: Yes, this product is CE certified.
Q: Where is this product manufactured?
A: This product is manufactured in China.
Q: What is the minimum order quantity for this product?
A: The minimum order quantity for this product is 1 set.
Q: What are the payment terms for this product?
A: The payment terms for this product are L/C, D/A, D/P, T/T, Western Union, and MoneyGram.
Q: What is the supply ability for this product?
A: The supply ability for this product is 10 sets per month.
Q: What is the delivery time for this product?
A: The delivery time for this product is 30 work days.
Q: How is this product packaged?
A: This product is packaged with stretch film and a wooden case.
