Air cooled Finned-tube Condenser

Air cooled Finned-tube Condenser

Product Details

An air-cooled finned-tube condenser is a device that utilizes ambient air as a cooling medium to condense gaseous refrigerant and dissipate heat through forced convection. Its core structure consists of a metal tube bundle (typically copper or stainless steel) integrated with fins characterized by high thermal conductivity.

As high-temperature, high-pressure gaseous refrigerant flows through the tubes, heat is conducted through the tube walls to the external fins. By extending the geometric surface area, the fins significantly enhance the air-side heat transfer coefficient, thereby compensating for the inherently poor thermal conductivity of air. Assisted by forced airflow generated by a fan, the unit rapidly dissipates heat, causing the refrigerant to condense into a liquid state. To optimize overall performance, modern designs often employ corrugated or louvered fins to disrupt the airflow field and reduce thermal resistance within the boundary layer. Furthermore, these condensers are designed for compactness and corrosion resistance—often featuring hydrophilic coatings—and are widely used in residential air conditioners, small-to-medium-sized cold storage facilities, and industrial refrigeration systems, serving as critical thermal components for efficient energy conversion.

Finned Evaporator Mold Specifications

Common Mold Specifications

Heat Exchanger Fin Materials and Shapes

Fin Evaporator Applications

Fin evaporators are widely used in air conditioning, refrigeration, and heat pump systems, thanks to their highly efficient, extended heat transfer surfaces. Their primary function involves using low-temperature refrigerant flowing inside the tubes to absorb heat from the air outside, thereby cooling and dehumidifying the air or facilitating precise heat transfer. These components serve as the core heat-absorbing elements in everything from household refrigerators and central air conditioning systems to industrial dehumidifiers and cold-chain transport equipment. Their lightweight design and superior convective heat transfer efficiency allow them to meet the requirements of various temperature zones. Through optimized fin spacing and specialized coatings, they effectively balance airflow resistance and frost resistance while maintaining high heat transfer performance, making them crucial for efficient energy conversion.

Application

Certificate

Packing & Delivery

The normal package is wooden box. If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.

Lead Time: 20 - 40 days
Payment Terms: 50% T/T payment in advance, 50% T/T payment before delivery
Packing Condition: Standard export packing or customized packaging

Our Advantages:

FAQ

WHO WE ARE :

Dongguan Xinju Air Conditioning Electromechanical Co., Ltd. is located in Dongguan City, China, covering a manufacturing area of 10,000 square meters. The company primarily manufactures heat exchangers to OEM customers and the HVAC industry, include fin condensers, evaporators, cooling coils, dry coolers, air coolers and varies metal sheet cases for the refrigeration industry, developing a reputation for high quality products and the ability to engineer a wide range of heating and cooling solutions.

Mission

The mission of Xinju Air-Conditioning M&E company is to provide heat transfer markets worldwide with high quality, cost effective products that are configured, manufactured, and shipped with the shortest lead times and fast friendly service.

Xinju understands that the future is crucially dependent on the success of our customers. Our management staff, and sales engineers are well respected in the industry and committed to constant improvement in development of new designs, manufacturing methods, and heat transfer technologies.

Our corporate philosophy is based on an uncompromising commitment to quality, customer service excellence, revolutionary product design, competitive pricing and on-time shipments. Customers can depend on Xinju Air Conditioning M&E engineering expertise to develop the proper design that insures proper coil performance for each unique application.

Markets

We serve a wide variety of markets and customers with an emphasis in the following industries:

· Industrial Refrigeration

· HVAC

· Power Generation

· Gas Compression

· Data Center

· Mining sites, chemical plants,

· Cinema & Theater, Art Center,

· Airport & Rail Transit.

With our ability to accurately predict the performance of our heat exchangers and build with a wide variety of materials, we welcome the opportunity to help you find creative and efficient heat transfer solutions for your process or products.

Our Advantages
 1.15+ Years Industry Experience:

Specialized in HVAC & refrigeration heat exchangers manufacturing.

2.Full Customization Service:

Custom size, material, fin design, anti-corrosion treatment and structure.
3.Strict Quality Control:

Standard production and testing to ensure stable and durable performance.
4.OEM & ODM Available:

Long-term cooperation for global HVAC OEM and engineering projects.
5.Fast Lead Time & Stable Delivery:

Complete production lines to meet bulk and urgent orders.

6.Professional Technical Support:

Quick quotation, technical selection and after-sales service worldwide.
