| Categories | Flex PCB Assembly |
|---|---|
| MOQ: | No MOQ |
| Supply Ability: | 100,000 pieces per month |
| Packaging Details: | ESD Protective Packaging/Customization |
| Delivery Time: | 5-25 working days(varies by product) |
| Place of Origin: | China |
| Price: | Quote based on your specs |
| Payment Terms: | T/T |
| Company Info. |
| Studio Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Overview
Full-service flexible PCB assembly from component sourcing through final shipping—all managed by one team, all under one roof. Studio Electronics offers Full-Service Flex PCB Assembly covering the complete production cycle. As a comprehensive provider of PCB assembly in China, we manage component procurement, FPC pre-treatment, custom carrier fabrication, SMT assembly, controlled reflow, inspection, and global logistics. Our 12 automated SMT lines, specialized FPC expertise, and comprehensive quality systems deliver reliable flexible assemblies for any application. This is the complete service.
Full-Service Coverage – Sourcing to Shipping
| Service Area | Studio Capability | Quality Assurance |
|---|---|---|
| Component Sourcing | Global supply chain; authorized distributors | Incoming inspection; LCR testing; traceability |
| FPC Fabrication | In-house flexible PCB fabrication | Material certification; controlled processes |
| Carrier Fixture | Custom design and CNC fabrication | Precision alignment; flatness verification |
| SMT Assembly | 12 automated SMT lines; ±25μm accuracy | SPI; AOI; real-time process monitoring |
| THT Assembly | Automatic wave soldering; robotic soldering | Solder joint verification; X-Ray inspection |
| Quality Testing | AOI; X-Ray; ICT; Flying Probe; FCT—100% | Documented results per board serial number |
| Final Assembly | Box-build; stiffener application | Functional verification; visual inspection |
| Logistics | Anti-static packaging; customs clearance | Packaging verification; tracking; delivery |
The Full-Service FPC Assembly Process
Stage 1: Component Sourcing – Components sourced through authorized distributors. For low volume PCB assembly, small-quantity procurement supported.
Stage 2: FPC Fabrication – In-house flexible PCB fabrication or customer-provided FPCs. Material verification and incoming inspection.
Stage 3: FPC Pre-Treatment – Pre-baking removes moisture from polyimide substrates.
Stage 4: Carrier Fixture – Custom carriers fabricated for each FPC design.
Stage 5: SMT Assembly – 12 SMT lines with dedicated FPC placement programs. ±25μm accuracy. Automatic wave soldering for through-hole.
Stage 6: Controlled Reflow – Low-temperature profiles protect polyimide substrates while achieving reliable solder joints.
Stage 7: Quality Inspection – 100% coverage: AOI; X-Ray; ICT; Flying Probe; FCT. Dynamic bend testing available.
Stage 8: Final Assembly & Shipping – Careful demounting; anti-static packaging; customs clearance; global logistics.
Why Full-Service FPC Assembly Matters
Studio delivers Full-Service Flex PCB Assembly—sourcing to shipping with specialized FPC expertise.
|
