UL94 V-0 certified White PU Potting for Electronic Components 6807 WT

BZ-6807(WT) is a premium white polyurethane potting compound with UL94 V-0 classification and RTI 130°C thermal rating, specifically developed for automotive electronics, vehicle subsystems, and low-altitude aircraft platforms. It delivers dependable flame retardation, thermal endurance, moisture/weather resistance, impact tolerance, and high dielectric strength to meet the most demanding protection requirements.

Key Product Features

1. User-Friendly Handling: Two-part white formulation with superior flow and wetting, compatible with both manual casting and automated dispensing equipment.
2. Global-Ready Compliance: Fully RoHS and REACH certified, simplifying international market entry with minimal regulatory friction.
3. Certified Fire/Thermal Integrity: UL94 V-0 listing and RTI-130°C recognition (UL Yellow Card QMFZ2.E352175) ensure proven safety under extreme conditions.
4. Versatile Performance Package: Integrates tenacious adhesion, wide-temperature stability, UV/weather resistance, high dielectric insulation, and robust mechanical durability.
5. Wide-Ranging Suitability: Engineered for automotive electronics, onboard controllers, sensor modules, and a broad spectrum of industrial electronic systems.

Technical Parameters

Product Applications

1. Low-Altitude Aircraft: Ultra-low density supports lightweight design, with flexible, durable properties and IP68 waterproofing for aerial use.
2. Automotive Electronics: Delivers superior electrical performance, vibration resistance, V-0 flame retardancy, thermal stability, and long-term reliability for critical vehicle systems.
3. Industrial Controllers & PCBs: RTI 130℃-rated high-temperature resilience, high thermal conductivity, efficient heat dissipation, and V-0 fire protection.
4. Sensors: Low-density formulation, V-0 flame retardancy, low dielectric constant, and low-temperature tolerance for precision applications.
5. General Electronics: V-0 flame retardancy, UL Yellow Card, and RTI 130℃ compliance, with electrical insulation and mechanical strength meeting most high-performance material needs.

Directions for Use

1. Pre-potting Preparation: Calibrate scales, prepare potting tools, cleaning tools, check machine settings, check vacuum pump force, etc.
2. Product Pre-treatment: Place product on a level surface or fixture. Remove dust, clean, degrease, and dry if necessary.
3. Accurate Proportioning: Manual operation requires precise mixing according to the specified ratio and recording. Machine potting requires calibrated ratios and first-article confirmation is recommended.
4. Mixing & Stirring: Manual operation requires thorough stirring or using electric stirrers to ensure homogeneous mixing. Machine potting requires sufficient stirring speed, adjust as needed.
5. Uniform Potting: Manual operation should be done in small, multiple batches to ensure uniformity. Machine potting should follow the programmed path for quantitative dispensing.
6. Inspection or Secondary Potting: After potting, visually inspect as needed. Perform touch-up, bubble removal, or secondary potting if required.
7. Curing: Allow the potted and inspected products to cure at room temperature or with heat assistance (recommended 60°C if needed), according to product and process requirements.
8. Final Product Confirmation: Perform visual inspection and performance testing as required by the customer.

Packing

1. Hardener: Typically 5KG/10KG/25KG/200KG metal or plastic drums.
2. Resin: Typically 25KG/200KG metal or plastic drums.
